Specifications

• MPU points: 20 (8DI/6DO, 4AI/2AO)
• Max. I/O points: 494 (14 + 480)
• Program capacity: 16k steps
• COM port: Built-in RS-232, RS-485 & USB ports, compatible with ASCII/RTU protocol. Can be master or slave.
• High-Speed Pulse Output: Supports 2 points (Y0, Y2) of 100kHz and 2 points (Y1, Y3) of 10kHz independent high-speed pulse output.
• Built-in High-Speed Counters
• Built-in Analog I/O
