DVP-SX2 Series
Dealer In India | Zentech Automation
DVP-SX2 Series
The 2nd generation DVP-SX2 series slim type PLC offers 14 digital points and built-in 12-bit analog I/O points. It is extendable with DVP-S series left-side and right-side extension modules.
Used for PID temperature/humidity control, 2-axis AC motor drive constant speed control, temperature control using a analog signal monitoring of a whole factory. (PLC EASY LINK)
Additional Information:
Specifications
- MPU points: 10 (4DI/2DO, 2AI/2AO)
- Max. I/O points: 230
- Program capacity: 8K Steps
- Communication port: Built-in RS-232 and RS-485, compatible with MODBUS ASCII / RTU communication protocol.
- High-speed pulse output: Supports 2-point independent high-speed pulse output (Y0 of up to 50KHz and Y1 of up to 10KHz).
- Built-in high-speed counter
- Built-in analog I/O function
