Features

• Small, light, powerful*1 and speedy
• *1 Middle and high inertia types only
• *2 MHMF200 W
• *3 MHMD200 W
• Significantly extended running range by the highest speed and high torque in the industry’s highest class.
• Enhanced position detecting resolution enables smoother and more precise positioning.
• Low vibrations. High speed and high precision positioning.
• *4 Incremental encoder
• Easy and quick setting, shortening conventional settling time by approx. 64%*1.
• Newly developed fit gain function substantially reduces adjustment time. Adaptive notch filter and various gains can be automatically set and adjusted.
• *1 Comparison with conventional product A5? Family
• Settling time: Adjustment completed in only 3 processes
• Realized 3.2 kHz frequency response to improve productivity.
• Realizes 3.2 kHz frequency response. At 139% that of conventional models*1, it enables high-speed operation and improves productivity.
• Reduced maintenance work and trouble.
• Lineup of motors protected by high dust-proof, high heat-resistant oil seal (With protective lip)
• Motors protected by a highly dust-proof, oil-tight oil seal (with protection lip) have been added to the lineup of motor products equipped with oil seals of conventional specifications. The oil seals of this type of motor are made of a material of higher heat resistance.
• You can select appropriate motor type according to your application environment such as dusty, powdery or gear connection necessity.
• Oil-seals (with protective lip) are not available for MSMF motors with flange size 80 mm or smaller.
• MQMF and MHMF motors with flange size of 80 mm or smaller provided with oil seals (with protective lip) are not mounting-compatible with A5 Family models.
• Some products are provided with ‘protective lip’ that prevents dust and oil penetration. IP67 enclosure rating (Motors with flange size of 80 mm or smaller are order-made products)
• Direct-mount connectors are used for the motor power supply and encoder input and output to improve sealing performance of the motor to IP67.
• IP67-compatible motors with flange size of 80 mm or smaller are order-made products.
• For environmental conditions of applications, refer to Motor Specification Description.
• Geared servomotor: The geared servomotor lineup is also added.
• Multifunctional software for quick adjustment support: PANATERM set-up support software
• The PANATERM set-up support software, with many added features, assists users in setting parameters, monitoring control conditions, setup support, and analyzing mechanical operation data on the PC screen, when installed in a commercially available personal computer, and connected to the MINAS A6 Family through the USB interface. Choose either English, Japanese, Chinese, or Korean-language display.
• Battery-less absolute encoder motor: Reduced the battery for the absolute encoder by installing the power generating element in the motor. In addition to improving maintainability, it supports the construction of ecological and economical industrial machines and systems.
