Compact Inductive Proximity Sensor GA-311/GH
The GA-311/GH series compact inductive proximity sensors are engineered to deliver precise and reliable object detection in space-constrained environments. With their small and robust design, these sensors are ideal for integration into tight spaces without compromising performance. The GA-311 models offer front sensing capabilities, while the GH models provide top sensing options, ensuring versatility for various applications. Equipped with NPN and PNP output configurations, they cater to diverse operational needs, supporting both Normally Open (NO) and Normally Closed (NC) outputs. These sensors are perfect for industrial automation, assembly lines, and packaging systems, where accuracy and compact design are crucial. Built to endure harsh operating conditions, the GA-311/GH series combines durability with high sensitivity, making it an excellent choice for demanding industrial environments.
Additional Information:
Order guide
Sensor heads
| Type | Appearance (mm in) | Sensing Range (Maximum operation distance) |
Sensing Range (Stable sensing range) |
Model No. | Hysteresis |
|---|---|---|---|---|---|
| Cylindrical type | 1.2 mm (0.047 in) |
0 to 0.6 mm (0 to 0.024 in) |
GH-2SE | 0.07 mm (0.0028 in or less) |
|
| 1.8 mm (0.071 in) |
0 to 0.8 mm (0 to 0.031 in) |
GH-3SE | 0.05 mm (0.0020 in or less) |
||
| 2.4 mm (0.094 in) |
0 to 1.0 mm (0 to 0.039 in) |
GH-5SE | – | ||
| 4.0 mm (0.157 in) |
0 to 2.0 mm (0 to 0.079 in) |
GH-8SE | 0.04 mm (0.0016 in or less) |
||
| Spatter resistant type | – | – | – | GH-F8SE | – |
Amplifier
| Type | Appearance | Model No. | Output Connector Type |
|---|---|---|---|
| Amplifier | – | GA-311 | NPN open-collector transistor |
Quick-connection cable
| Type | Model No. | Description |
|---|---|---|
| Main cable (3-core) | CN-73-C1 | Length: 1 m (3.281 ft), 0.2 mm? 3-core cabtyre cable, with connector on one end, Cable outer diameter: ?3.3 mm (?0.130 in) |
| Main cable (3-core) | CN-73-C2 | Length: 2 m (6.562 ft), 0.2 mm? 3-core cabtyre cable, with connector on one end, Cable outer diameter: ?3.3 mm (?0.130 in) |
| Main cable (3-core) | CN-73-C5 | Length: 5 m (16.404 ft), 0.2 mm? 3-core cabtyre cable, with connector on one end, Cable outer diameter: ?3.3 mm (?0.130 in) |
| Sub cable (1-core) | CN-71-C1 | Length: 1 m (3.281 ft), 0.2 mm? 1-core cabtyre cable, with connector on one end, Cable outer diameter: ?3.3 mm (?0.130 in) |
| Sub cable (1-core) | CN-71-C2 | Length: 2 m (6.562 ft), 0.2 mm? 1-core cabtyre cable, with connector on one end, Cable outer diameter: ?3.3 mm (?0.130 in) |
| Sub cable (1-core) | CN-71-C5 | Length: 5 m (16.404 ft), 0.2 mm? 1-core cabtyre cable, with connector on one end, Cable outer diameter: ?3.3 mm (?0.130 in) |
End plates
| Appearance | Model No. | Description |
|---|---|---|
| MS-DIN-E | MS-DIN-E | When cascading multiple amplifiers, or when it moves depending on the way it is installed on a DIN rail, these end plates clamp amplifiers into place on both sides. Make sure to use end plates when cascading multiple amplifiers together. [ 2 pcs. per set ] |
