Specifications

• MPU points: 12 (8DI + 4DO)
• Max. I/O points: 492 (12 + 480)
• Program capacity: 16k steps
• COM port: Built-in RS-232 & 2 RS-485 ports, compatible with Modbus ASCII/RTU protocol. Can be master or slave.
• High-Speed Pulse Output: Supports 2 points (Y0, Y2) of 100kHz and 2 points (Y1, Y3) of 10kHz independent high-speed pulse output.
• Extendable to Max. 8 Modules: DVP-SA2 is extendable to analog I/O, temperature measurement, input DIP switch, PROFIBUS/Device Net communication modules, and single-axis motion control functions.
• Built-in High-Speed Counters
