Features & Benefits

• Nickel Coated Brass: Ensures durability and resistance to corrosion.
• Standard Sensors for Ferrous Metals Detection: Designed to detect ferrous metals, offering precision and reliability.
• IP67 and CE Certification: Provides protection against dust and water ingress, with CE certification for compliance with European safety standards.
• Electrical Circuit Protection: Prevents damage to the electrical circuits, ensuring safe operation and longevity.

Applications

• Food and Beverages: Ideal for use in hygienic environments where metal detection is crucial.
• Packaging: Suitable for packaging machinery that requires metal detection.
• Pharmacy: Helps in detecting metal contaminants in pharmaceutical production.
• Electronic Component Equipment: Essential for detecting ferrous metals in electronics manufacturing.
• Textile: Used in textile production to prevent metal contaminants from damaging machines.
• Rubber and Plastics: Provides metal detection for manufacturing processes in these industries.
• Warehouses: Helps in the detection of metal objects in warehouse settings.
• Machine Tool Industries: Used in machine tools to detect metal parts for efficient operation.

Specifications

• Sensing Distance: 2 mm ? 10%, 4 mm ? 10%, 5 mm ? 10%, 8 mm ? 10%, 12 mm ? 10%
• Differential Travel: max. 10% of sensing distance
• Detectable Object: Ferrous metal
• Power Supply Voltage (Operating Voltage Range): 12 to 24 VDC, ripple (p-p): max. 10%
• Current Consumption: 15 mA max
• Output:
  • Load Current: 200 mA max
  • Residual Voltage: 2V max. (load current: 200 mA, cable length: 2 m)
• Indicators: Operation indicator (red)
• Operation Mode (with Sensing Object Approaching): NPN: NO / NC; PNP: NO / NC
• Ambient Temperature Range: Operating: -25 ~ +70 ?C / Storage: -40 ~ 80 ?C (with no icing or condensation)
• Connection Method: 3 wires 2m cable and M12 connector with 200mm cable
